Investment Castings




Investment casting is a manufacturing process that uses a wax part for each required piece. The refractory slurry hardens into a mold and the shell is filled with molten metal. The shell is removed and the new metal part is left.



Broad Range of Capabilities

Powered by our advanced-technology and high-precision casting equipment as well as extensive industry experience,, we manufacture investment castings from a broad variety of metal materials. These materials range from  stainless steel, alloy steel, copper alloy, aluminum alloy, super alloy, carbon steel, to cast iron, with various specifications, sizes and weights.

We have fully integrated capabilities including in-house tooling design and manufacturing, heat treatment, machining, surface treatment, and other finishing services.



Advanced Technologies

Our investment casting facilities are equipped with industry-leading production equipment, such as automatic wax injection machines, robotic wax pattern assembly machines, robotic shell making systems, vacuum furnaces and five-axis and four-axis CNC machining centers.

The annual production capacity of investment castings exceeds 12,000 tons.



Rapid Product Development
With our vertically integrated manufacturing solutions, the lead time for new product development can be as short as 4 weeks. In particular, with ProJet 3-D rapid prototyping technology, we can directly manufacture high quality and high-precision complex models and produce prototype parts in as little as a week. The product development cycle time can thereby be significantly shortened, and allow our customers to quickly react to the market.


Critical Components Solutions to Diversified Industries

We sell our investment casting products to all our major end markets. Our key investment casting products include engine parts, automotive parts, aerospace parts and medical parts.


Process Capabilities



Process

Weight

Size Limit

Melting

Lost Wax

0.03~100kg/1oz to 220 lbs

600mm/24”

Vacuum and Air



Material Capabilities



Stainless Steel

Martensitic Stainless Steel: 100 Series, ZG1Cr13, ZG2Cr13 and more

Ferritic stainless steel: 200 Series, ZG1Cr17, ZG1Cr19Mo2 and more

Austenitic stainless steel: 300 Series, 304, 304L, CF3, CF3M, CF8M, CF8, 1.4308, SUS304 and more

Duplex Stainless Steel: 400 Series, ZG1Cr17Mn9Ni4Mo3CU2n

Precipitation Hardening Stainless Steel: 500 Series, 17-4PH, 15-5PH and more



Low Alloy Steel
IC4140, IC8620, 16MnCr5, 42CrMo4 and more



Carbon Steel

A216 WCB, A216 WCA, 1020, 1045, 1050, ZG230-450, ZG340-640 and more


Cast Iron
Ductile Iron: QT-400-18, QT400-15, QT450-10, QT500-6, QT600-3, QT700-2, QT800-2, QT900-2 and more

Grey Iron: HT200, HT250, GG-15, GG-25, G2500, EN-GJL-200 and more



Super Alloy
Nickel-based and cobalt-based alloy and more


 Aluminum Alloy
A356, A355, ZL101, ZL108 and more



Copper Alloy
C87500, C87600, C92600, C95500, C95400, C93200, M0580 and more



High Precision Products
Launch Slideshow +
Global Manufacturing Facilities

We operate several state-of-the-art investment casting manufacturing facilities globally including 3 plants (Plant 1, Plant 3, Plant 5) in China, 2 plants (BFG-H, BFG-M) in Germany and 1 plant (BFG-Cz) in the Czech Republic
