Precision Machining Parts




Precision machining parts are metal parts processed by machine tools.


Complete Precision Machining Solutions
Impro possesses extensive industrial experience and advanced machining equipment and technology in the area of precision machining parts. Impro’s precision machining facilities are well equipped with the most advanced devices including:

            Multi-Tasking Turning Center
        CNC Machining Center
       CNC Lathes
       Precision Honing
       Center-less Grinding, Cylindrical Grinding and Internal Grinding
       Deburring
       4-Axis and 5-Axis Machining Centers

This allows us to handle various special processes, such as precision honing, deburring, hard turning and high-precision O.D. grinding. Together with facilities for heat treatment and surface treatment as well as our laboratories, we are able to provide our customers with comprehensive one-stop precision machining part solutions. The annual production capacity of precision machining parts exceeds 24 million pieces.

Rapid Product Development

With more than ten years of extensive technology know-how, we are able to shorten our product development cycles for various types of products to as short as three days. Such a short development cycle significantly reduces the product development cost of our customers and facilitates their speedy go-to-market strategies.


Core Applications of our High Precision Products

We process precision machining parts for:

automotive industry

hydraulic equipment

heavy-duty  and high horsepower engines

aerospace industry

medical industry



Examples of our precision machining components include spools, pistons, sleeves, flight control system parts, air system parts and automotive fuel system parts.


Precision Machining Parts Processes and Capability


Process

Size Limit
Accuracy
 Grinding
 Surface
 Φ750×300mm
 0.002mm
 Grinding
 O.D.
 Φ200×500mm
 0.001mm
 Grinding
 I.D.
 Φ100×100mm
 0.005mm
 Grinding
 CNC I.D.Grinding
 Φ100×150mm
 0.005mm
 Grinding
 Centerless Grinding
 Φ100×500mm
 0.001mm
 Turning CNC
 620×1200mm
 620×1200mm
 0.01mm
 Milling CNC
 1020×510×625mm
 1020×510×625mm
 0.01mm


Special Machining Process


Precision Honing

Honing hole diameters range from 3mm to 50mm, tolerance 0.005mm



Deburring

We have full range of deburring capabilities including electrolytic deburring, thermal deburring and abrasive flow deburring. We employ advanced deburring technology for hydraulic, automotive and aerospace components with crossing holes and complex inner cavity to meet stringent deburring requirements.



Hard Turning

Our hard turning process enables us to machine parts with hardness over 58 HRC after heat treatment, maximum turning diameter of 20mm, dimensional tolerance 0.005mm, roughness Ra0.2μm



High Precision O.D. Grinding

The precision grinding capability is employed for shafts with diameter within 200mm, length within 400mm, diameter tolerance of 0.001mm.



High Precision I.D. & O.D. (Universal O.D. Grinding)

The precision grinding capability enables us to machine shafts with diameter within 350mm, length within 1000mm, roundness of 0.0004mm, and cylindricity of 0.001mm. Inner holes range from 3mm to 100mm.

Key Raw Materials for Precision Machining Parts



Bar, tube, hexagonal profile and other profiles



Carbon Steel and Structural Steel

1020, 1045, Q345B and more



Free Cutting Steel

1215, 12L14, 1144 and more


Spring Steel

1066 and more



Bearing Steel

52100,440C and more


Tool Steel

M2, M50, D2, A2, S7 and more



Aluminum Alloy

6061-T6,7075-T6 and more


Alloy Steel

Low-carbon alloy steel:16Mn, 16MnCr5, 4118, 8620 and more

Medium-carbon alloy steel: 4140, 4340 and more

Nitrided alloy steel:31CrMoV9, 34CrAlMo5V and more



Stainless Steel

Austenitic stainless steel: 303, 304, 316 and more

Stainless steel: 410, 420, and more

Precipitation-Hardening Stainless Steel: 17-4PH, 15-5 and more









High Precision Products
Launch Slideshow +
State-of-the-Art Facilities

We possess two world-class precision machining facilities, Plant 2 and Plant 3 in Wuxi Jiangsu, China.
